Galvanized Iron Welded Mesh from China manufacturer - Dingzhou yongchang metal products company limited

Price:	0.55~5.55 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: yc008

Production Capacity: 1000 square meter per day

Delivery Date: about 15 days

Type: Welded

Brand Name: yongchang

Means of Transport: Ocean,Land,Air

Packing: as your request

Application: Filter

Material: Brass Wire

Mesh Size: 100-400 mesh

Wire Dia:4-14mm;
Aperture:50-400mm
Length*Width:2400*6000mm

Materials:High quality low carbon steel wire,stainless steel wire, pvc

Weaving and characteristic:Including gavanizining after weaving.Gavanining before

weaving.It is divided into hot-dipped electroplate gavanizing,PVCcoating,plastic-soake,.spectric welded wire mesh.It has thecharcteristice of corrosion-resisting andoxidation-resisiting.

Uses:Widely used in industry,agriculture,building,transportation,mine,field,lawn,
cultivation,protection fence,decoration,machine protection etc

Diameter:12#-24#
Aperture:1/4''-2''
Width:3'-6'
best price
factory producing

Specification List of Welded Wire Mesh
Opening		Wire Diameter<BWG>
In inch	In metric unit(mm)	Wire Diameter<BWG>
1/4" x 1/4"	6.4mm x 6.4mm	22,23,24
3/8" x 3/8"	10.6mm x 10.6mm	19,20,21,22
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8" x 5/8"	16mm x 16mm	18,19,20,21,
3/4" x 3/4"	19.1mm x 19.1mm	16,17,18,19,20,21
1" x 1/2"	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2" x 1-1/2"	38mm x 38mm	14,15,16,17,18,19
1" x 2"	25.4mm x 50.8mm	14,15,16
2" x 2"	50.8mm x 50.8mm	12,13,14,15,16
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.

PVC Coated Welded Mesh
Opening		Wire Diameter<BWG>
In inch	In metric unit(mm)	Wire Diameter<BWG>
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21
3/4" x 3/4"	19mm x 19mm	16,17,18,19,20,21
1" x 1"	25.4mm x 25.4mm	15,16,17,18,19,20
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.2m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.
